Specifications

Product Type	Surge Filter
Brand	NOVARIS
Connection Type	Series
Degree of Protection	IP20
Depth	182 mm
Display Type	LED Power and Thermal Failure
Fuse Rating	125 A
Height	450 mm
Humidity	5-95%
Lightning Impulse Current	25 kA
Modes of Protection	L-N, L-PE, N-PE
Mounting Type	Panel
Number of Ports	2
Operational Temperature	-40 to 70 deg C
Phase	3
Rated Current	125 A
Rated Short Circuit Current	50 kA
Rated Voltage	230 VAC
Standards and Approvals	IEC 61643-11:2011, AS/NZS 1768:2007
Voltage Protection Level	<360 V
Weight	24 kg
Width	390 mm
