Specifications

Product Type	Surge Filters
Brand	Novaris
Series	SFM3
Application	Critical installations, sensitive electronics and computer equipment
Lightning Impulse Current Iimp (10/350µs)	25kA (L-N)100kA (N-PE)
Max. Backup Fuse	63A
Max. Continuous Operating Voltage (AC/DC)	275VAC (L-N)255VAC (N-PE)
No. of Poles (Total)	3
Nominal Voltage	230V
Nominal Discharge Current (8/20µs)	80kA (L-N)100kA (N-PE)
Voltage Protection Level Up	<1000V
Maximum Discharge Current Imax (8/20µs)	50kA
Alarm Contact	SPST NC
Mounting Method	Panel
Terminal Size	Terminal capacity - power 35mm²Terminal capacity - alarms 2.5mm²
Depth	190 mm
Height	450 mm
Width	390 mm
Operating Temperature	-40°C - 70°C
IP Rating	IP20
