Specifications

Product Type	Spark Gap Surge Diverter
Brand	Novaris
Series	SG3
Application	Power, Main Switchboards, Commercial and Industrial (Highly Exposed)
Lightning Impulse Current Iimp (10/350µs)	50 kA
Max. Backup Fuse	500 A
Max. Continuous Operating Voltage (AC/DC)	275 V AC
No. of Phases	3
Rated Voltage	275 VAC
Nominal Voltage	230 V AC
Nominal Discharge Current (8/20µs)	50 kA
Voltage Protection Level Up	1300 V
Max. Discharge Current Imax (8/20µs)	150 kA
Short Circuit Current Rating	25 kA
Alarm Contact	SPDT power and thermal failure
Nominal Discharge Current Inom (8/20µs)	50 kA
Mounting Method	TS35 DIN Rail
Terminal Size	35 mm2
Depth	91 mm
Height	67 mm
Width	108 mm
Humidity	5-95%
Operating Temperature	-40°C to 70°C
IP Rating	IP20

Novaris SG3-50-275 Spark Gap Arrester 3 PH 50kA 275VAC 144mm W 90mm D 66mm H
