Specifications

Product Type	Slimline Signal Line Protectors
Brand	Novaris
Series	SL
Application	Signal, Process Control, Input/Output/Comms
Connection Type	Screw Cage
Lightning Impulse Current Iimp (10/350µs)	1.25 kA
No. of Lines/Pairs	1 pair
Modes of Protection	Transverse and Common Modes
Rated Current	5 kA (Per Line), 10 kA (Common Mode)
Rated Voltage	3 VDC
Line Resistance	3.9 Ohm
Response Time	<5 ns
Voltage Protection Level Up	15 V
Max. Discharge Current Imax (8/20µs)	5 kA
With Base	G Direct Earthing
Max. Continuous Operating Voltage (DC)	7 V DC
Max. Continuous Operating Voltage (AC)	5 V AC
Housing Material	Polycarbonate
Material	Polycarbonate
Mounting Method	TS35 DIN Rail
Mounting Type	TS35 DIN Rail
Terminal Size	2.5 mm2
Tightening Torque	0.5 N-m
Depth	102 mm
Height	68 mm
Weight	35 g
Width	7 mm
Humidity	5-95%
Operating Temperature	-40°C to 70°C
IP Rating	IP20
Standards and Approvals	IEC 61643-21:2012, AS/NZS 1768:2007, UL 1499 3rd Edition and UL 497B, ITU-T K.44: 2012, AS/CA S008:2010, AS/NZS 4117:1999
