Specifications

Product Type	SL1-M Surge Protector
Brand	Novaris
Series	SL1
Application	Signal, Process Control, Input/Output/Comms
Rated Current	3 kA
Rated Voltage	275 V
Nominal Voltage	230 V AC
Voltage Protection Level Up	800 V
Max. Discharge Current Imax (8/20µs)	20 kA
Nominal Discharge Current Inom (8/20µs)	10 kA
Max. Continuous Operating Voltage (DC)	350 V DC
Max. Continuous Operating Voltage (AC)	275 V AC
Mounting Method	Universal TS32 and TS35 rail
Terminal Size	2.5 mm2
Depth	68 mm
Height	62 mm
Width	6 mm
Operating Temperature	-25°C to 70°C
IP Rating	IP20

Novaris SL1-M275 Slimline Signal Line Protector 3kA 275V
