Specifications

Product Type	Multiline Signal Line Protector
Brand	Novaris
Connection Type	Series
No. of Lines/Pairs	12
Modes of Protection	Transverse and Common Modes
Rated Current	20 kA
Rated Voltage	65 VDC
Line Resistance	8.2 Ohm
Mounting Method	Panel mount
Mounting Type	Panel
Tightening Torque	0.5 N-m
Depth	42 mm
Height	80 mm
Weight	250 g
Width	128 mm
Humidity	5-95%
Operating Temperature	-40 to 85 deg C
IP Rating	IP20
Standards and Approvals	IEC61643-21, ITU-T K.44, AS/NZS 1768, IEEE C62.41, UL497B

Novaris SLM-68 Multiline Signal Line Protector 20kA 65VDC Panel Mount 128mm W 42mm D 80mm H IP20
