Specifications

Product Type	Surge Protector
Brand	NOVARIS
Series	SSP6A
Base Type	EC90 Indirect Earthing
Capacitance	48 nF
Connection Type	Series
Degree of Protection	IP20
Depth	68 mm
Height	102 mm
Humidity	5-95%
Material	Polycarbonate
Modes of Protection	Transverse and Common Modes
Mounting Type	TS35 DIN Rail
Number of Lines	1 pair
Operational Temperature	-40 to 70 deg C
Rated Current	4.8 kA (Per Line), 9.6 kA (Common Mode)
Rated Voltage	14 VDC
Resistance	0.02 Ohm
Response Time	<5 ns
Standards and Approvals	IEC 61643-21:2012, AS/NZS 1768:2007, UL 1499 3rd Edition and UL 497B, ITU-T K.44: 2012, AS/CA S008:2010, AS/NZS 4117:1999
Suitable For Use With	Twisted Pair Signaling
Tightening Torque	0.5 N-m
Voltage Protection Level	35 V
Weight	35 g
Width	7 mm
