Specifications

Product Type	Slimline Series Surge Protectors
Brand	Novaris
Series	SSP6A
Application	Signal, Process Control, Input/Output/Power
Connection Type	Series
Max. Continuous Operating Voltage (AC/DC)	11 V AC, 14 V DC
Max. Load Current	6 A
No. of Lines/Pairs	1 pair
No. of Phases/Lines	1 pair
Suitable For	Twisted Pair Signaling
Modes of Protection	Transverse and Common
Rated Current	4.8 kA (Per Line), 9.6 kA (Common Mode)
Rated Voltage	14 VDC
Line Resistance	0.02 Ohm
Response Time	<5 ns
Voltage Protection Level Up	45 V, 380 V, 620 V
Max. Discharge Current Imax (8/20µs)	5 kA
With Base	G Direct Earthing
Material	Polycarbonate
Mounting Method	TS35 DIN Rail
Mounting Type	TS35 DIN Rail
Terminal Size	2.5 mm2
Tightening Torque	0.5 N-m
Depth	102 mm
Height	68 mm
Weight	35 g
Width	7 mm
Humidity	5-95%
Operating Temperature	-40°C to 70°C
IP Rating	IP20
Standards and Approvals	IEC 61643-21:2012, AS/NZS 1768:2007, UL 1499 3rd Edition and UL 497B, ITU-T K.44: 2012, AS/CA S008:2010, AS/NZS 4117:1999
