Specifications

Product Type	Triangular Key
Brand	SCHMERSAL
Actuator Material	Stainless steel
Actuator Type	Rod Lever
Bounce Duration	Bounce duration in accordance with actuating speed
Cable Entry	3 x M20 x 1.5
Connection Type	M12 Plug
Connector Type	Connector plug M12, 4-pole
Contact Configuration	NO+NC
Contact Material	Gold-plated silver (AgNi 15 + Au 0.3µm)
Degree of Protection	IP67
Depth	36.1 mm
Design	Round
Enclosure Coating Material	Painted
Front Ring Material	ABS, chrome-plated
Height	111 mm
Housing Material	Plastic, Reinforced Glass Fibre
Installation Conditions	Flush
Mounting Type	Flange
Operational Temperature	80 deg C
Overvoltage Category	3
Rated Current	1000 A
Rated Power	8.5 W
Rated Voltage	75 VDC
Sealing Type	Form seals / Lip gaskets / Membrane
Sensor Size	30 mm L x 90 mm H
Shock Resistance	50 g/ms
Standards and Approvals	EN IEC 60947-5-1
Terminal Type	Connector M12
Version	Y-adapter
Width	82 mm
