Specifications

Product Type	BN 32-01
Brand	Schmersal
Series	BN 32
Configuration Type	Opener (NC)
No. of N/C Contacts	1
No. of N/O Contacts	0
Switching Current	3 A
Switching Element	Reed Contacts
Switching Voltage	250 V AC
Type of Switching Output	Magnetic Drive
Accuracy	0.3 mm
Contact Configuration	NC
Electrical Connection	Flat plug-in connector 4.8 mm
Rated Current	3 A
Rated Voltage	250 VAC
Switching Capacity (AC)	120 W
Mechanical Durability	1000000000 Operations
Actuator Type	Magnet
Housing Material	Glass Fibre Reinforced Thermoplastic
Material	Glass-fibre, reinforced thermoplastic
Shock Resistance acc. To IEC/EN 60068-2-27	15 g/ms
Depth	24 mm
Height	26 mm
Weight	58 g
Width	85 mm
Operating Temperature	-25 to 90 degC
IP Rating	IP00
