Schmersal 101061111 Position Switch Roller Lever 1NO-1NC Grey Cast Iron Galvanized Silver Contact

Product Code: 101061111

1

Specifications

Product Type	Position Switch
Brand	Schmersal
Series	471 roller lever A
No. of N/C Contacts	2
No. of N/O Contacts	2
Rated Insulation Voltage (Ui)	500 V
Type of Switching Output	Slow Action
Contact Configuration	1NO+1NC
Rated Current	10A (AC-15)
Rated Voltage	230V AC (AC-15)
Terminal Type	Screw
Mechanical Durability	1000000 Operations
Thermal Test Current	25A
Actuator Type	Roller lever
Cable Cross Section	1.5 sq-mm
Connecting Capacity	(2) 4 mm
Contact Material	Silver
Enclosure Material	Painted
Housing Material	Grey cast iron, galvanised
Depth	190 mm
Height	143mm
Weight	4,920 g
Width	194mm
IP Rating	IP65
Ambient Temperature	-30 ... +90 °C
Standards and Approvals	ENIEC 60947-5-1
