Specifications

Product Type	Magnetic Reed Switch
Brand	SCHMERSAL
Series	BN 85
Cable Length	1 m
Switching Element	Reed Contacts
Type of Switching Output	Magnetic Drive
Rated Current	1 A
Rated Voltage	60 VDC
Switching Capacity (AC)	30 W
Mechanical Durability	1000000000 Operations
Actuator Type	Magnet
Housing Material	Glass Fibre Reinforced Thermoplastic
Mounting Type	Threaded
Shock Resistance acc. To IEC/EN 60068-2-27	60 g/ms
Weight	43 g
Operating Temperature	0 to 75 deg C
IP Rating	IP40
