Specifications

Product Type	Magnetic safety sensor
Brand	Schmersal
Series	BNS 250
Cable Length	6 m
No. of N/C Contacts	2
No. of N/O Contacts	1
Rated Current	0.01 A
Rated Frequency	5 Hz
Rated Power	0.24 W
Rated Voltage	24 V DC
Mechanical Durability	25000000 Cycles
Actuator Type	BPS 250
Housing Material	Glass-fibre, reinforced thermoplastic
Mounting Type	Not Flush
Shock Resistance acc. To IEC/EN 60068-2-27	30 g/ms
Vibration Resistance acc. To IEC/EN 60068-2-6	10-150 Hz
Depth	13 mm
Height	25 mm
Weight	214 g
Width	33 mm
Size	0.25 sq-mm
Operating Temperature	-25 to +70 °C
IP Rating	IP67
Standards and Approvals	cULus
Enclosure Dimensions	13 mm L x 33 mm W x 25 mm H
