Schmersal 101163570 Pushbutton Roller Lever

Product Code: 101163570

  • High protection rating: IP67, IP69K
  • Operates in -25 to 80°C temperature range
  • Durable with 1 million operations lifespan
  • Strong vibration resistance of 20 g
  • Roller lever actuator for precise control
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Product Type Mushroom Pushbutton
Brand SCHMERSAL
Actuating Torque 0.15 N-m
Actuator Type Roller Lever
Ambient Temperature -25 to 80 deg C
Bezel Colour Blue, Silver
Bezel Material ABS
Degree of Protection IP67, IP69K
Diameter 44.5 mm
Front Ring Material ABS, chrome-plated
Fully Insulated Yes
Mechanical Life 1 million Operations
Mounting Type Flange
Operator Material ABS
Shock Resistance 30 g/ms
Standards and Approvals EN IEC 60947-1, EN IEC 60947-5-1
Tightening Torque 0.6 N-m
Vibration Resistance 20 g

Description

<p>When considering industrial and commercial applications, reliability and durability are paramount. This product offers a robust solution with its impressive technical specifications, making it suitable for various demanding environments.</p><p>Designed for resilience, this product features a degree of protection rated at IP67 and IP69K, ensuring it can withstand harsh conditions such as dust ingress and high-pressure water jets. The ambient temperature range from -25 to 80 degrees Celsius further highlights its adaptability to extreme temperatures, making it an excellent choice for both indoor and outdoor settings.</p><p>The actuator type is a roller lever, known for its efficiency in mechanical operations. With an actuating torque of 0.15 N-m and tightening torque of 0.6 N-m, the device promises precise control with minimal effort required from users. Its mechanical life is rated at one million operations, indicating long-term reliability that minimizes maintenance needs over time.</p><p>In terms of physical construction, the bezel is made from ABS material—a durable choice that balances strength with lightweight properties. Available in blue and silver colors, the bezel not only provides aesthetic flexibility but also ensures visibility in varied lighting conditions or design schemes.</p><p>Mounting this device is straightforward due to its flange mounting type. This simplifies installation processes while maintaining secure attachment in application settings prone to vibrations or shocks—factors accounted for with vibration resistance up to 20 g and shock resistance at 30 g/ms.</p><p>Meeting industry standards EN IEC 60947-1 and EN IEC 60947-5-1 assures compliance with international safety regulations, providing peace of mind regarding operational safety across global markets.</p><p>Overall, this product stands out as a reliable component engineered for longevity under challenging circumstances without compromising on performance or safety standards—an essential consideration when selecting components for critical industrial applications.</p>
