Specifications

Product Type	Magnetic safety sensor
Brand	Schmersal
Series	BNS30
No. of N/C Contacts	1
No. of N/O Contacts	0
Contact Configuration	1NC
Rated Current	3 A
Rated Frequency	5 Hz
Rated Power	750 W
Rated Voltage	250 VAC
Actuator Type	Magnet
Housing Material	Brass
Mounting Type	Quasi-Flush
Shock Resistance acc. To IEC/EN 60068-2-27	30 g/ms
Vibration Resistance acc. To IEC/EN 60068-2-6	10-55 Hz
Operating Temperature	-25 to 55 deg C
IP Rating	IP67
Standards and Approvals	BG-GS-ET-14; EN IEC 60947-5-3; EN ISO 13849-1
Enclosure Dimensions	78 mm L
