Schmersal 101182505 Magnetic Reed Switch 3A BP 15/2 BP 20 BP 10 Screw Terminal

Product Code: 101182505

In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

Product Type Magnetic Reed Switch
Brand SCHMERSAL
Series NT24K
Accuracy 0.3 mm
Actuating Element Magnet
Actuating Speed 18 m/s
Actuator Type Angle roller lever
Bounce Duration 0.3 ms
Contact Material Silver
Control Element Reed Contacts
Degree of Protection IP67
Housing Material Die Cast Light Alloy, Painted
Mechanical Life 1000000000 Operations
Operational Temperature -25 to 70 deg C
Rated Current 3 A
Rated Voltage 250 VAC
Resistance 10-55 Hz
Standards and Approvals EN IEC 60079-0, EN IEC 60079-15, EN 60079-31
Switching Capacity 120 W
Switching Type Magnetic Drive
Terminal Type Screw terminals M20 x 1.5

Documents

IPD Product Catalogue V17
Installation
Instructions
SCHMERSAL Datasheet

Certificate

EU Declaration of Conformity

CAD Blocks & Dimensions
