Schmersal 101187203 Solenid Interlock Switch 24VAC/VDC 2NC+2NO

Product Code: 101187203

  • 24 VAC/VDC, 6A rated voltage and current
  • Durable aluminium housing, IP67 protection
  • Slow action with 0.2 m/s actuating speed
  • Long-lasting: 1 million mechanical cycles
  • Complies with cULus, CCC, UKCA standards
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Product Type Solenid Interlock Switch
Brand SCHMERSAL
Series AZM415
Action Slow Action
Actuating Force 15 N
Actuating Speed 0.2 m/s
Contact Configuration 2NC+2NO
Contact Material Silver
Degree of Protection IP67
Housing Material Aluminium
Mechanical Life 1000000 Cycles
Operational Temperature 50 deg C
Rated Current 6 A
Rated Insulation Voltage 250 V
Rated Power 10 W
Rated Voltage 24 VAC/VDC
Sensor Size 46.5 mm L x 100 mm H
Standards and Approvals cULus, CCC, UKCA

Description

<p>The AZM415 series offers a robust solution for industrial and commercial applications, designed to meet the demanding requirements of modern automation systems. This safety switch combines durability with precision, ensuring reliable performance across various environments.</p><p>Operating at a rated voltage of 24 VAC/VDC and supporting a current of up to 6 A, the AZM415 is well-suited for integration into diverse electrical systems. With a rated power of 10 W, it balances efficiency and effectiveness, making it an ideal choice for energy-conscious operations.</p><p>The contact configuration features 2 normally closed (NC) and 2 normally open (NO) contacts. This setup provides flexibility in circuit design while maintaining operational integrity. The contacts are crafted from silver, enhancing conductivity and longevity even under frequent use.</p><p>Built to withstand rigorous conditions, the AZM415 boasts an impressive mechanical life of one million cycles. Its aluminium housing material further contributes to its resilience by offering protection against physical impacts and environmental factors. The IP67 degree of protection ensures that the device remains unaffected by dust ingress and temporary submersion in water.</p><p>Designed for optimal performance within an operational temperature range up to 50 degrees Celsius, this switch can handle varied climatic conditions without compromising functionality. It adheres to multiple standards including cULus, CCC, and UKCA approvals—affirming its compliance with international safety regulations.</p><p>The slow action mechanism enhances control over operations by providing deliberate engagement at an actuating speed of 0.2 m/s with a force requirement of just 15 N. This feature is particularly beneficial in applications where precision is paramount.</p><p>Measuring at a compact sensor size of 46.5 mm in length by 100 mm in height, the AZM415 fits seamlessly into tight spaces while delivering robust performance. Additionally, it supports a rated insulation voltage of up to 250 V which ensures safety during operation.</p><p>In summary, the AZM415 series stands out as a dependable component for those seeking reliability coupled with high-performance standards in their technical setups.</p>
