Specifications

Product Type	EX-BN 20-10Z-3G/D
Brand	Schmersal
Series	EX-BN 20
Configuration Type	Normally open contact (NO)
No. of N/C Contacts	0
No. of N/O Contacts	1
Switching Current	3 A
Switching Element	Reed Contacts
Switching Voltage	250 V AC, 250 V DC
Type of Switching Output	Magnetic Drive
Accuracy	0.3 mm
Electrical Connection	Screw terminals M20 x 1.5
Rated Current	3 A
Rated Voltage	250 VAC
Switching Capacity (AC)	120 W
Mechanical Durability	1000000000 Operations
Actuator Type	Magnet
Housing Material	Die Cast Light Alloy, Painted
Material	Light-alloy diecast, paint finish
Vibration Resistance acc. To IEC/EN 60068-2-6	10-55 Hz
Depth	47 mm
Height	52 mm
Weight	315 g
Width	104 mm
Operating Temperature	-15 to 70 degC
IP Rating	IP67
Standards and Approvals	EN IEC 60079-0, EN IEC 60079-15, EN 60079-31
