Schmersal 101193763 Magnetic Reed Switch 3A BP 10 Screw Terminal

Product Code: 101193763

In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

Product Type Magnetic Reed Switch
Brand SCHMERSAL
Series NT24K
Accuracy 0.3 mm
Actuating Element Magnet
Actuating Speed 18 m/s
Bounce Duration 0.3 ms
Control Element Reed Contacts
Degree of Protection IP67
Housing Material Die Cast Light Alloy, Painted
Mechanical Life 1000000000 Operations
Operational Temperature -25 to 70 deg C
Rated Current 3 A
Rated Voltage 250 VAC
Resistance 10-55 Hz
Standards and Approvals EN IEC 60079-0, EN IEC 60079-15, EN 60079-31
Switching Capacity 120 W
Switching Type Magnetic Drive
