Schmersal 101195530 Magnetic Reed Switch 3A BP 10 Screw Terminal

Product Code: 101195530

In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

Product Type Magnetic Reed Switch
Brand SCHMERSAL
Accuracy 0.3 mm
Actuating Element Magnet
Actuating Speed 18 m/s
Control Element Reed Contacts
Housing Material Aluminium
Mechanical Life 1000000000 Operations
Operational Temperature -25 to 90 deg C
Rated Current 3 A
Resistance 50 g/ms
Standards and Approvals EN IEC 60947-5-1
Switching Capacity 120 W
Switching Type Magnetic Drive
Weight 292 g

Documents

IPD Product Catalogue V17
Instructions
SCHMERSAL Datasheet

Certificate

EU Declaration of Conformity

CAD Blocks & Dimensions
