Specifications

Product Type	Solenoid Interlock Switch
Brand	Schmersal
Series	MZM 100
Switching Current	4 A (AC-15), 1 A (DC-13)
Rated Voltage	24 V AC/ DC (control)
Terminal Type	Connector M12, 8-pole
Operating Mode	Power-to-lock
Guard Locking Force	750 N
Housing Material	Glass-fibre reinforced thermoplastic
Depth	40 mm
Height	179 mm
Weight	0.618 kg (approx.)
Width	40 mm
IP Rating	IP67
Ambient Temperature	-25 °C to +50 °C
