Schmersal 151168060 Position Switch with Safety Function 230VAC, 24VDC NC

Product Code: 151168060

1

Specifications

Product Type	Position Switch
Brand	Schmersal
No. of N/C Contacts	1
Rated Insulation Voltage (Ui)	500 V
Switching Principle	Magnet Snap Action
Contact Configuration	NC
Rated Current	4 A
Rated Voltage	230 VAC, 24 VDC
Terminal Type	Screw terminals
Contact Material	Silver
Housing Material	Plastic
Weight	55 g
Operating Temperature	-30 to 80 deg C
IP Rating	IP65
Standards and Approvals	BG-GS-ET-15, EN IEC 60947-5-1
Enclosure Dimensions	31 mm L x 30 mm W x 72 mm H

Documents

IPD Product Catalogue V17

SCHMERSAL Datasheet

Certificate

Certificate of Compliance
