Novaris RJ45-16CAT6 Network Protector 1kA 2kA 5kA 10kA 4VAC RJ45 Socket Rack Mount 88mm H Steel IP20

Product Code: RJ45-16CAT6

  • Rated for 5 kA per line, 10 kA common mode
  • RJ45 socket connection, easy rack mount
  • Operates in -40 to 70°C, IP20 protection
  • Fast response time <5 ns
  • Compliance with IEC, UL, and AS standards
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Dimensions (mm) 88H x 20W x 483L
Lightning Impulse Current (10/350 &#181;s) - Iimp (kA) 1, 2 (common mode)
Maximum Continuous Operating Voltage MCOV AC (V) 4
Maximum Continuous Operating Voltage MCOV DC (V) 6
Maximum Discharge Current (8/20µs) - Imax (kA) 5, 10 (common mode)
Operational Temperature Range (&#176;C) -40 to 70
No. of Pairs 4
Voltage Protection Level (1kV/&#181;s) - Up (kV) <0.02 (L-L) < 0.35 (L-PE)
Maximum Load Current - I? (A) 1
Product Type Network Protector
Brand NOVARIS
Connection Type RJ45 Socket
Degree of Protection IP20
Height 88 mm
Humidity 5-95%
Length 483 mm
Lightning Impulse Current 1 kA, 2 kA
Material Steel
Modes of Protection Transverse and Common Modes
Mounting Type Rack
Number of Pairs 4
Number of Ports 16
Operational Temperature -40 to 70 deg C
Rated Current 5 kA (Per Line), 10 kA (Common Mode)
Rated Voltage 4 VAC
Response Time <5 ns
Standards and Approvals IEC 61643-21, AS/NZS 1768, UL 497B, ITU-T K.44, AS/CA S008, AS/NZS 4117, AS/CA S009
Terminal Type RJ45 Socket
Voltage Protection Level <0.02 kA (L-L), <0.35 kA (L-PE)
Weight 1.85 kg
Width 20 mm

Description

The RJ45 network protector is designed to protect twisted pair Ethernet systems. It has 16 RJ45 ports with 4 pairs and a shield. The maximum continuous voltage it can handle is 6 VDC and 4 VAC. It has a maximum common mode discharge current of 5kA at 8/20 ms (common mode 10kA) and a maximum discharge current of 1kA at 10/350 us (common mode 2kA). The maximum load current it can handle is 1A. It provides voltage protection levels of &lt;20V (L-L) and &lt;350V (L-PE) at a series connection rate of 1 kV/ms. This network protector is rack mountable and has an IP20 rating.
