IPD IT18A25N ENCAPSUL. CHASSIS 18P 250A TEE-OFF FD 18mm PITCH

Product Code: IT18A25N

The Encapsulated Chassis 18P is designed for a 250A tee-off feed with an 18mm pitch. It has a withstand rating of Icw 25kA/0.1s and 10kA/1s, as well as an Icc rating of 30kA. The chassis features 2mm thick copper incoming terminals and a 1.2mm thick galvanized iron base. It is coated with duravin SCI-TV, making it suitable for S200 breakers in the IA range IPD.

Technical Specifications

Brand IPD
Current Rating (A) 250
Feed Type Tee-off Feed
No. of Poles 18
Pitch Size (mm) 18
Poles 18
Rated Current (A) 250
Type of Feed Tee-Off Feed
