Specifications

Dimensions (mm)	73W x 90H x 18D
No. of Poles	2
Nominal Discharge Current (8/20µs) - In (kA)	2
Nominal Voltage AC (V)	60
Reference No.	953203
Suitable For	Power Supply Systems
Total Discharge Current (8/20µs) - Itotal (kA)	4
Weight (kg)	0.079
Nominal Load Current AC - I? (A)	25
Weight (g)	89.8
Mounting Method	DIN rail (top hat rail) 35 mm
Maximum Continuous Voltage DC (V)	75
Maximum Continuous Voltage AC (V)	75
Product Type	Surge Arrester
Brand	DEHN
Degree of Protection	IP20
Depth	18 mm
Height	90 mm
Mounting Type	DIN Rail
Number of Poles	2
Phase	1
Rated Current	2 kA
Rated Voltage	75 VDC
Standards and Approvals	EN 61643-1
Suitable For Use With	Power Supply Systems
Weight	89.8 g
Width	73 mm
