When it comes to safeguarding your electrical systems, choosing a reliable surge filter is crucial. This particular surge filter is designed with industrial and commercial applications in mind, offering robust protection for sensitive equipment.
Operating at a rated voltage of 230 VAC and supporting a current of up to 10 A, this device caters to two-phase systems efficiently. Its compact design measures 118 mm in width, 69 mm in height, and 95 mm in depth, making it suitable for installations where space might be limited. The unit weighs 850 g and is constructed from durable aluminium material that ensures long-lasting performance.
One of the standout features of this surge filter is its LED thermal failure display type, providing clear visual alerts for any issues that may arise during operation. With an IP20 degree of protection rating, it’s ideally suited for indoor environments where dust ingress needs to be minimal but not necessarily moisture-proof.
For ease of installation and maintenance, this model can be mounted on a TS35 DIN rail—a common standard in many industrial settings—allowing for streamlined integration into existing systems. It operates reliably across a wide temperature range from -40°C to 70°C and handles humidity levels between 5% and 95%, ensuring consistent performance even under challenging environmental conditions.
In terms of safety standards and approvals, this surge filter has been rigorously tested to comply with IEC 61643-11:2011, AS/NZS 1768:2007, UL 1449 (3rd Edition), as well as IEEE 62.41.2:2002 guidelines—providing peace of mind regarding its compliance with international safety benchmarks.
The device offers rapid response time (<100 ns) particularly effective against transient overvoltages between Line-to-Peak Earth (L-PE). It also provides modes of protection including Line-to-Line (L-L) alongside L-PE pathways which are critical for comprehensive system security against surges.
Furthermore, the voltage protection level remains below <600V (L-L), ensuring that connected devices are shielded from potentially damaging voltages without compromising normal operational parameters.
This surge filter stands out as an efficient solution tailored towards professionals seeking dependable electrical infrastructure protection within their facilities while adhering strictly to technical requirements essential for Australian markets.
