IDEC RL2B-D-A200 Power Relay 2 DPST 200-240VAC Coil 25A Quick Connect Terminal

Product Code: RL2B-D-A200

  • Operates at 200-240 VAC with 25 A current
  • Quick connect terminals for easy installation
  • Durable DIN rail mounting design
  • IP40 rated for solid object protection
  • Certified CE, cRuUS, RoHS, VDE compliant
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Contacts 2X (DPST, Double Make)
Coil Voltage AC (V) 200 - 240
Dimensions (mm) 54W x 50H x 39.5D
No. of Poles 2
Operational Temperature Range (°C) -25 to 55
Power Consumption (VA) 1.7 - 2.5
Maximum Switching Current (A) 25
Weight (g) 90-135
Minimum Mechanical Life 1,000,000
Operating Humidity 5 to 85%
Resistance to Vibrations 10 to 55Hz
Resistance to Shock (m/s²) 1000
Terminal Shape Quick Connect Terminal
Product Type Power Relay
Brand IDEC
Contact Configuration 2 DPST
Contact Material Ag Alloy
Degree of Protection IP40
Humidity 5-85%
Mechanical Life 1000000 Operations
Mounting Type DIN Rail
Number of Poles 2
Operating Time 30 ms
Operational Temperature -25 to 55 deg C
Rated Current 25 A
Rated Power 1.7-2.5 VA
Rated Voltage 200-240 VAC
Shock Resistance 1000 ms
Standards and Approvals CE, cRuUS, RoHS, VDE
Terminal Type Quick Connect
Vibration Resistance 10-55 Hz
Weight 90-135 g

Description

The IDEC RL2B-D-A200 is a 2-pole tab terminal DIN relay, rated for 200V AC applications. It features Double Make contacts, making it suitable for controlling motor, lighting, and heater loads. This relay is designed to meet RoHS compliance standards, ensuring environmentally safe use. Its robust construction makes it a reliable choice for industrial control systems.
