When it comes to selecting a dependable pushbutton for industrial and commercial applications, the YW Series stands out with its robust design and reliable performance. This pushbutton is engineered to meet the diverse needs of Australian technical professionals who prioritize functionality and compliance with industry standards.
The pushbutton operates effectively at a rated voltage of 230/240 VAC/DC, making it versatile for various electrical environments. Its illuminated feature, facilitated by a built-in red LED lamp, ensures visibility even in dimly lit conditions, enhancing operational efficiency. With dimensions measuring 30 mm in width, 41.4 mm in height, and 64.8 mm in depth, this device offers a compact yet substantial presence suitable for control panels where space is often at a premium.
Designed to withstand challenging environments, the pushbutton boasts an IP65 front degree of protection against dust and water ingress while maintaining an IP20 rating at the terminal level. It operates reliably across temperatures ranging from -20 to 55 degrees Celsius and can be stored safely between -40 to 85 degrees Celsius. These attributes ensure that the product remains functional under varying climatic conditions typical of industrial settings.
In terms of durability, the YW Series excels with a mechanical life expectancy of up to five million operations for single contact blocks and one million operations for double contact blocks. The actuator type is extended with a diameter cutout size of 22 mm, matching standard panel requirements seamlessly.
Safety certifications are paramount; hence this pushbutton is cULus listed, CE marked, UKCA certified, and CCC certified—assuring users that it meets rigorous international safety standards. Additionally, its rated insulation voltage stands at an impressive 600 V with insulation resistance measured at 100 MOhm.
For those concerned about environmental factors such as vibration or shock during operation or transport—the device offers vibration resistance from 5-55 Hz and shock resistance up to 10 g/ms—ensuring consistent performance without compromise.
The momentary function combined with its contact configuration (1NO+1NC) allows flexibility in control applications whether used as part of emergency stop systems or machine start functions. Furthermore, it supports a rated continuous current of up to 10 A which aligns well with most medium-duty electrical circuits encountered in industrial setups.
Constructed using durable metal bezel materials coupled with humidity tolerance ranging from 45-85%, this pushbutton promises longevity alongside reliability—a key consideration for any professional seeking cost-effective solutions over time.
In summary: The YW Series Pushbutton delivers on multiple fronts—from operational reliability under varied conditions through adherence to international safety standards—all wrapped within a user-friendly design tailored specifically towards meeting technical demands efficiently without unnecessary complexity or frills.
