IDECHW1B-M1F10Y-K Non-Illuminated Pushbutton 22mm Flush Momentary Yellow 1NO

Product Code: HW1B-M1F10Y-K

  • Non-illuminated flush actuator, 22 mm diameter
  • IP65 front protection for robust use
  • Screw terminals ensure secure connections
  • Rated insulation voltage of 600 V
  • Momentary function with 1NO contact configuration
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Contacts 1NO
Insulation Resistance (MO) 100
Mounting Hole Diameter (mm) 22
Operational Temperature Range (°C) -25 to + 60
Rated Continuous Current (A) Contact Rating - 10
Pollution Degree 3
Rated Frequency (Hz) 50/60
Rated Insulation Voltage (V) Contact Rating - 600
Rated Impulse Withstand Voltage (kV) 4
Tightening Torque (Nm) Locking Ring - 2.0
Product Type Pushbutton
Brand IDEC
Series HW
Actuator Type Flush
Bezel Colour Black
Bezel Material Plastic
Bezel Shape Round
Button Colour Yellow
Colour Yellow
Contact Configuration 1NO
Contact Material Silver
Cutout Size 22 mm
Degree of Protection IP65 Front, IP20 Terminal
Diameter 22 mm
Function Momentary
Humidity 45-85%
Illumination Non-Illuminated
Insulation Resistance 100 MOhm
Mode of Operation Momentary
Operational Temperature -25 to 60 deg C
Rated Continuous Current 10 A
Rated Insulation Voltage 600 V
Terminal Type Screw

Description

The IDEC HW1B-M1F10Y-K is a non-illuminated, yellow pushbutton designed for momentary operation. It features a flush design with one normally open (NO) contact and finger-safe terminals for enhanced safety. The pushbutton's tamperproof construction ensures secure use in various applications.
