IDECHW1B-M1F22-B Non-Illuminated Pushbutton 22mm Flush Momentary Black 2NO+2NC

Product Code: HW1B-M1F22-B

  • Non-illuminated pushbutton, flush actuator
  • IP65 front protection for durability
  • 2NO+2NC contact configuration
  • Screw terminals for secure connections
  • Operates in -25 to 60°C environments
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

No. of Normally-open Contacts 2
No. of Normally-closed Contacts 2
Terminal Shape Screw terminal
Product Type Pushbutton
Brand IDEC
Series HW
Actuator Type Flush
Bezel Colour Black
Bezel Material Plastic
Bezel Shape Round
Button Colour Black
Colour Black
Contact Configuration 2NO+2NC
Contact Material Silver
Cutout Size 22 mm
Degree of Protection IP65 Front, IP20 Terminal
Diameter 22 mm
Function Momentary
Humidity 45-85%
Illumination Non-Illuminated
Insulation Resistance 100 MOhm
Operational Temperature -25 to 60 deg C
Rated Continuous Current 10 A
Rated Insulation Voltage 600 V
Terminal Type Screw

Description

The IDEC HW1B-M1F22-B is a 22mm black pushbutton designed for quick and momentary actions. Its flush design and plastic bezel ensure durability and ease of use in various applications. This pushbutton is ideal for control panel interfaces requiring a compact and efficient switching solution.

Documents

  • IPD Product Catalogue

    IPD Product Catalogue V17
