The HW Series pushbutton is a robust and reliable component designed to meet the demanding needs of industrial and commercial applications. This non-illuminated pushbutton features a mushroom actuator type, ensuring ease of use with its large surface area. The button is blue, providing clear visibility in various settings.
Engineered for durability, this pushbutton operates effectively within a temperature range of -25 to 60 degrees Celsius, making it suitable for diverse environments. It offers an IP65 degree of protection at the front, which means it's dust-tight and protected against water jets from any direction. Meanwhile, the terminal side provides an IP20 rating for basic protection against finger access.
The contact configuration is 1NO (normally open), with contacts made from silver, known for excellent conductivity and reliability over time. The rated insulation voltage stands at 600 V, while the rated continuous current capacity is 10 A—suitable for most standard applications requiring dependable performance.
Installation is straightforward thanks to its screw terminal type. The cutout size matches its diameter at 29 mm, ensuring compatibility with standard panel designs. Its round bezel shape complements a variety of control panels aesthetically while being functional; crafted from plastic in black color adds to its versatility.
For those concerned about environmental factors like humidity, this pushbutton can operate efficiently in conditions ranging from 45% to 85%. Additionally, it boasts an impressive insulation resistance of 100 MOhm—indicative of high-quality construction that minimizes leakage currents and ensures operational safety.
Overall, this HW Series pushbutton combines functionality with resilience—a practical choice for engineers seeking a reliable solution that fits seamlessly into their systems without unnecessary complexity or compromise on quality.
