IDECHW1B-M1F22-G Non-Illuminated Pushbutton 22mm Flush Momentary Green 2NO+2NC

Product Code: HW1B-M1F22-G

  • Non-illuminated, flush green button
  • IP65 front protection for durability
  • 2NO+2NC silver contacts for reliability
  • Screw terminals for secure connections
  • Operates in -25 to 60°C environments
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

No. of Normally-open Contacts 2
No. of Normally-closed Contacts 2
Terminal Shape Screw terminal
Product Type Pushbutton
Brand IDEC
Series HW
Actuator Type Flush
Bezel Colour Black
Bezel Material Plastic
Bezel Shape Round
Button Colour Green
Colour Green
Contact Configuration 2NO+2NC
Contact Material Silver
Cutout Size 22 mm
Degree of Protection IP65 Front, IP20 Terminal
Diameter 22 mm
Function Momentary
Humidity 45-85%
Illumination Non-Illuminated
Insulation Resistance 100 MOhm
Operational Temperature -25 to 60 deg C
Rated Continuous Current 10 A
Rated Insulation Voltage 600 V
Terminal Type Screw

Description

The IDEC HW1B-M1F22-G is a green, flush pushbutton designed for momentary operation. It features a durable plastic bezel and is suitable for 22mm mounting applications. This pushbutton offers a straightforward interface for control systems in various industrial settings.

Documents

  • IPD Product Catalogue

    IPD Product Catalogue V17
