IDECHW1B-M1F01-R Non-Illuminated Pushbutton 22mm Flush Momentary Red 1NC

Product Code: HW1B-M1F01-R

  • Non-illuminated, flush red actuator
  • IP65 front protection, IP20 terminals
  • Screw terminal connection
  • SEMI S2 standards approved
  • 22 mm round plastic bezel
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Terminal Shape Screw terminal
Product Type Pushbutton
Brand IDEC
Series HW
Actuator Type Flush
Bezel Colour Black
Bezel Material Plastic
Bezel Shape Round
Button Colour Red
Colour Red
Contact Configuration 1NC
Contact Material Silver
Cutout Size 22 mm
Degree of Protection IP65 Front, IP20 Terminal
Diameter 22 mm
Function Momentary
Humidity 45-85%
Illumination Non-Illuminated
Insulation Resistance 100 MOhm
Operational Temperature -25 to 60 deg C
Rated Continuous Current 10 A
Rated Insulation Voltage 600 V
Standards and Approvals SEMI S2
Terminal Type Screw

Description

The IDEC HW1B-M1F01-R is a robust 22mm red pushbutton designed for secure and safe operations. It features finger-safe IP20 contacts and tamperproof construction, ensuring user protection and device integrity. This emergency stop pushbutton complies with EN60947-5-5 and SEMI S2 standards, meeting stringent safety requirements. Ideal for applications demanding high reliability and security, this pushbutton is engineered to maintain functionality in critical situations.
