IDECHW1B-M1F20-Y Non-Illuminated Pushbutton 22mm Flush Momentary Yellow 2NO

Product Code: HW1B-M1F20-Y

  • Non-illuminated, momentary pushbutton
  • Flush actuator with 22 mm diameter
  • Durable IP65 front protection
  • Screw terminal connections
  • Rated for 600 V insulation voltage
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

No. of Normally-open Contacts 2
Terminal Shape Screw terminal
Product Type Pushbutton
Brand IDEC
Series HW
Actuator Type Flush
Bezel Colour Black
Bezel Material Plastic
Bezel Shape Round
Button Colour Yellow
Colour Yellow
Contact Configuration 2NO
Contact Material Silver
Cutout Size 22 mm
Degree of Protection IP65 Front, IP20 Terminal
Diameter 22 mm
Function Momentary
Humidity 45-85%
Illumination Non-Illuminated
Insulation Resistance 100 MOhm
Operational Temperature -25 to 60 deg C
Rated Continuous Current 10 A
Rated Insulation Voltage 600 V
Terminal Type Screw

Description

The IDEC HW1B-M1F20-Y is a 22mm yellow pushbutton designed for quick and responsive operation. Its flush, momentary action ensures precise control, while the durable plastic bezel offers a robust interface for industrial environments. This pushbutton is an ideal solution for applications requiring a reliable and easily accessible switch.

Documents

  • IPD Product Catalogue

    IPD Product Catalogue V17
