ABB 24-60V 50/60HZ DC MECHANICAL LATCHING UNIT WA4-11

Product Code: WA4-11

WA4-11 is a mechanical latching unit for AF09(Z) ... AF65 contactors and NF(Z) contactor relays ensuring that the contactor or contactor relay remains switched on even if there is a lack or a failure of voltage, in application such as energy conservation. Standard contactors can be easily converted into compact latched contactors. The WA4 block contains a mechanical latching device with electromagnetic impulse unlatching (AC or DC) or manual unlatching. Extend your auxiliary control circuit by adding additional 1-pole front mounted CA4 and 2-pole side mounted CAL4 auxiliary contact blocks. Design easily your installation with 25% less depth required in panel mounting. Reduce your stock and increase your solution proposal with 50% of less variants required compared to conventional solutions.

Technical Specifications

Control Circuit Connecting Capacity Flexible with Ferrule 1/2 x 0.75 - 2.5mm² Flexible with Insulated Ferrule 1 x 0.75 - 2.5mm² Flexible with Insulated Ferrule 2 x 0.75 - 1.5mm² Rigid Solid 1/2 x 1 - 2.5mm² Rigid Stranded 1/2 x 1 - 2.5mm²
Brand ABB
Dimensions (mm) 19.8W x 41H x 67.4D
Rated Control Circuit Voltage AC/DC (V) 24 - 60
Rated Insulation Voltage (V) 690
Rated Operational Voltage AC/DC (V) 24 - 60
Standards and Approvals IEC/EN 60947-4-1, UL 60947-1, UL 60947-4-1
Suitable For AF09 - AF65
Terminal Type Screw
Type Mechanical Locking
Weight (kg) 0.065
Wire Stripping Length (mm) Control Circuit: 10
