Specifications

Product Type	Pushbutton
Brand	ABB
Actuator Type	Mushroom
Bezel Colour	Green
Bezel Material	Plastic
Connecting Capacity	Flexible with Ferrule 1/2 x 0.5 - 1.5 sq-mm, Flexible with Insulated Ferrule 1/2 x 0.5 - 1.5 sq-mm, Flexible 1/2 x 0.5 - 1.5 sq-mm, Solid 1/2 x 0.5 - 1.5 sq-mm
Connection Type	Screw Clamp
Contact Configuration	1NO
Degree of Protection	IP3, IP66, IP67, IP69K Front, IP20 Terminal
Diameter	40 mm
Enclosure Type	NEMA 1, 12, 13, 3R, 4, 4x
Function	Momentary
Illumination	Non-Illuminated
Operational Temperature	-25 to 70 deg C
Rated Frequency	50/60 Hz
Rated Impulse Withstand Voltage	6 kV
Rated Insulation Voltage	300 V
Rated Operational Current	0.2 A
Rated Thermal Current	5 A
Rated Voltage	300 VAC
Standards and Approvals	IEC/EN 60073, IEC/EN 60529, IEC/EN 60947-1, IEC/EN 60947-5-1, IEC/EN 60947-5-5
Storage Temperature	-40 to 85 deg C
Terminal Type	Screw
Tightening Torque	1 N-m
Wire Stripping Length	6 mm
