IDECYW1L-M4E10Q0A Illuminated Pushbutton 40mm Mushroom Momentary Amber 250VAC/DC 1NO

Product Code: YW1L-M4E10Q0A

  • Illuminated pushbutton with mushroom actuator
  • IP65 front protection for harsh environments
  • 5 million operations mechanical life
  • Wide operating temp range: -20 to 55°C
  • cULus, CE, UKCA, and CCC certified
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Contacts 1NO
Conventional Free-Air Thermal Current - Ith (A) Contact Rating - 10
Insulation Resistance (MO) 100
Mushroom Diameter (mm) 40
Mounting Hole Diameter (mm) 22
Operational Temperature Range (°C) -20 to +55
Rated Frequency (Hz) 50/60
Rated Insulation Voltage (V) Contact Rating - 600
Lamp Not Included
Product Type Pushbutton
Brand IDEC
Series YW
Actuator Type Mushroom
Bezel Material Plastic
Bezel Type Plastic
Contact Configuration 1NO
Contact Material Silver
Cutout Size 40 mm
Degree of Protection IP65 Front, IP20 Terminal
Depth 64.8 mm
Diameter 40 mm
Function Momentary
Height 41.4 mm
Humidity 45-85%
Illumination Illuminated
Insulation Resistance 100 MOhm
Lamp Colour Amber
Lamp Type Without Lamp
LED Colour Amber
Mechanical Life 5 million Operations Single Contact Block, 1 million Operations Double Contact Block
Mode of Operation Momentary
Operational Temperature -20 to 55 deg C
Rated Continuous Current 10 A
Rated Insulation Voltage 600 V
Rated Voltage 250 VAC/DC
Shock Resistance 10 g/ms
Standards and Approvals cULus listed, CE Marked, UKCA Certified, CCC Certified
Storage Temperature -40 to 85 deg C
Terminal Type Screw
Vibration Resistance 5-55 Hz
Width 30 mm

Description

The IDEC YW1L-M4E10Q0A is a non-illuminated, amber-colored mushroom pushbutton designed for momentary operation with a 1NO contact configuration. It features a 40mm diameter and is suitable for 22mm panel mounting. The pushbutton ensures safety with its IP20 protection rating and finger-safe terminals. Ideal for industrial applications requiring quick and secure actuation.

Documents

  • IPD Product Catalogue

    IPD Product Catalogue V17
