IDECYW1L-M4E10Q0Y Illuminated Pushbutton 40mm Mushroom Momentary Yellow 250VAC/DC 1NO

Product Code: YW1L-M4E10Q0Y

  • Illuminated mushroom actuator for clear visibility
  • IP65 front protection ensures durability
  • Operates effectively from -20 to 55°C
  • Mechanical life up to 5 million operations
  • cULus, CE, UKCA, CCC certified for compliance
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Contacts 1NO
Conventional Free-Air Thermal Current - Ith (A) Contact Rating - 10
Insulation Resistance (MO) 100
Mushroom Diameter (mm) 40
Mounting Hole Diameter (mm) 22
Operational Temperature Range (°C) -20 to +55
Rated Frequency (Hz) 50/60
Rated Insulation Voltage (V) Contact Rating - 600
Lamp Not Included
Product Type Pushbutton
Brand IDEC
Series YW
Actuator Type Mushroom
Bezel Material Plastic
Bezel Type Plastic
Contact Configuration 1NO
Contact Material Silver
Cutout Size 40 mm
Degree of Protection IP65 Front, IP20 Terminal
Depth 64.8 mm
Diameter 40 mm
Function Momentary
Height 41.4 mm
Humidity 45-85%
Illumination Illuminated
Insulation Resistance 100 MOhm
Lamp Colour Yellow
Lamp Type Without Lamp
LED Colour Yellow
Mechanical Life 5 million Operations Single Contact Block, 1 million Operations Double Contact Block
Mode of Operation Momentary
Operational Temperature -20 to 55 deg C
Rated Continuous Current 10 A
Rated Insulation Voltage 600 V
Rated Voltage 250 VAC/DC
Shock Resistance 10 g/ms
Standards and Approvals cULus listed, CE Marked, UKCA Certified, CCC Certified
Storage Temperature -40 to 85 deg C
Terminal Type Screw
Vibration Resistance 5-55 Hz
Width 30 mm

Description

The IDEC YW1L-M4E10Q0Y is a non-illuminated, yellow mushroom pushbutton designed for momentary operation. It features a large 40mm actuator for easy activation and includes a single Normally Open (1NO) contact. This pushbutton ensures secure installation with its 22mm mounting system and offers enhanced safety with IP20 finger-safe terminals. Ideal for various industrial applications where quick and safe switching is required.
