IDECYW1B-M4E10S Non-Illuminated Pushbutton 40mm Mushroom Momentary Blue 1NO

Product Code: YW1B-M4E10S

  • Non-illuminated blue mushroom actuator
  • IP65 front protection for durability
  • 5M operations mechanical life (single contact)
  • Screw terminals for secure connections
  • Rated insulation voltage of 600 V
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Contacts 1NO
Conventional Free-Air Thermal Current - Ith (A) Contact Rating - 10
Insulation Resistance (MO) 100
Operational Temperature Range (°C) -20 to +55
Rated Frequency (Hz) 50/60
Rated Insulation Voltage (V) Contact Rating - 600
Mushroom Diameter (mm) 40
Mounting Hole Diameter (mm) 22
Product Type Pushbutton
Brand IDEC
Series YW
Actuator Type Mushroom
Bezel Material Plastic
Bezel Type Plastic
Button Colour Blue
Colour Blue
Contact Configuration 1NO
Contact Material Silver
Cutout Size 40 mm
Degree of Protection IP65 Front, IP20 Terminal
Depth 66.3 mm
Diameter 40 mm
Function Momentary
Height 41.4 mm
Humidity 45-85%
Illumination Non-Illuminated
Insulation Resistance 100 MOhm
Mechanical Life 5 million Operations Single Contact Block, 1 million Operations Double Contact Block
Mode of Operation Momentary
Operational Temperature -20 to 55 deg C
Rated Continuous Current 10 A
Rated Insulation Voltage 600 V
Shock Resistance 10 g/ms
Standards and Approvals cULus listed, CE Marked, UKCA Certified, CCC Certified
Storage Temperature -40 to 85 deg C
Terminal Type Screw
Vibration Resistance 5-55 Hz
Width 30 mm

Description

The IDEC YW1B-M4E10S is a non-illuminated, blue mushroom pushbutton designed for robust performance. It features a momentary action with a 40mm diameter and a 1NO contact configuration. Engineered for 22mm mounting, this pushbutton ensures safety with finger safe terminals and an IP20 rating, providing protection against dust and touch. Ideal for applications requiring dependable and secure actuation.
