DEHN BXTML2BES48 Lightning Current Arrester 9kA 2.5kA 0.75A 48V 8.7MHz 45mm H IP20

Product Code: BXTML2BES48

  • Compact design: 12mm width
  • High temp range: -40 to 80°C
  • IP20 protection rating
  • Lightning impulse current: 9 kA total
  • Complies with IEC and UL standards
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Product Type Lighting Current Arrestor
Brand DEHN
Capacitance <=0.35 nF
Colour Yellow
Degree of Protection IP20
Depth 51 mm
Height 45 mm
Lightning Impulse Current 9 kA (Total), 2.5 kA (Per Line)
Material Polyamide
Mounting Type On Basic Element
Operational Temperature -40 to 80 deg C
Rated Current 0.75 A
Rated Frequency 8.7 MHz
Rated Voltage 48 V
Resistance 1.8 Ohm
SPD Class Type 1
Standards and Approvals IEC 61643-21/EN 61643-21, CSA, UL 497B, ATEX, IECEx, CSA and USA Hazloc, SIL
Suitable For Use With Blitzductor XT
Voltage Protection Level <=160V (L-L for Iimp D1 (UP), <=95V (Line-PG) for Iimp D1 (UP), <=140V (L-L at 1 kV/µs C3 (UP), <=70V (Line-PG) at 1 kV/µs C3 (UP)
Weight 21 g
Width 12 mm

Description

<p>When it comes to safeguarding your electrical systems, a reliable Surge Protection Device (SPD) is essential. This SPD stands out with its robust design and features tailored for industrial and commercial applications. Operating at a rated voltage of 48 V and a current of 0.75 A, this device is engineered to protect sensitive equipment from harmful surges.</p><p>The compact dimensions—12 mm in width, 45 mm in height, and 51 mm in depth—make it an ideal choice for space-constrained setups. Despite its small size, the SPD doesn&amp;#39;t compromise on durability or performance. With an IP20 degree of protection, it offers adequate resistance against dust ingress while being housed in durable polyamide material.</p><p>This SPD operates efficiently across a broad temperature range from -40 to 80 degrees Celsius, making it suitable for diverse environmental conditions. Its compliance with rigorous standards such as IEC 61643-21/EN 61643-21, CSA, UL 497B, ATEX, IECEx, CSA and USA Hazloc ensures reliability and safety in various applications.</p><p>Weighing just 21 grams, the device maintains high performance without adding unnecessary bulk. It supports a rated frequency of up to 8.7 MHz and is specifically designed for use with Blitzductor XT systems.</p><p>In terms of electrical characteristics, the SPD has a capacitance of less than or equal to 0.35 nF and resistance at approximately 1.8 Ohms. The voltage protection levels are impressive: up to &amp;lt;=160V (L-L for Iimp D1), &amp;lt;=95V (Line-PG) for Iimp D1), &amp;lt;=140V (L-L at C3), and &amp;lt;=70V (Line-PG at C3). These figures demonstrate its capability to effectively shield your equipment from transient voltage spikes.</p><p>Additionally, the product handles lightning impulse currents up to a total of 9 kA or up to 2.5 kA per line efficiently underlining its robustness as a Type 1 SPD class device.</p><p>Available in yellow color for easy identification within complex setups this surge protector combines practical design with advanced technology ensuring that your systems remain protected against unforeseen electrical disturbances.</p>
