Panasonic EX-F61 Leak Detection Sensor 12-24VDC NPN-Output

Product Code: EX-F61

  • Operates on 12-24 VDC, 15 mA current
  • Durable PFA body with IP67 protection
  • Quick response time under 50 ms
  • Infrared LED for reliable detection
  • CE, RoHS, UL recognized standards
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Product Type Leak Detection Sensor
Brand PANASONIC
Degree of Pollution IP3
Degree of Protection IP67
Emitting Element Infrared LED (Non-Modulated)
Housing Material PFA Body
Humidity 35-85%
Illuminance 1000 lx
Material Body-PFA
Mounting Type Bracket
Operational Temperature -20 to 70 deg C
Output Type NPN
Rated Current 15 mA
Rated Voltage 12-24 VDC
Response Time <50 ms
Standards and Approvals CE, RoHS, UL Recognition
Weight 0.06 kg

Description

<p>In the realm of industrial and commercial safety, precision and reliability are paramount. This Safety Sensor stands as a robust solution designed to meet stringent operational demands with ease. Operating at a rated voltage of 12-24 VDC and drawing a minimal current of 15 mA, this sensor is engineered for efficiency without compromising on performance.</p><p>The sensor&amp;#39;s output type is NPN, making it compatible with various control systems that require sinking inputs. Mounting is facilitated by a bracket system, ensuring secure installation in diverse environments. The housing material is crafted from PFA (Perfluoroalkoxy), known for its excellent chemical resistance and durability, promising longevity even in challenging conditions.</p><p>With an IP67 degree of protection, this sensor offers complete dust ingress protection and can withstand immersion in water up to one meter depth temporarily. Its pollution degree rating of IP3 indicates suitability for environments where conductive pollution must be expected occasionally or where condensation may occur.</p><p>Operating effectively within temperatures ranging from -20 to 70 degrees Celsius, the sensor adapts well to fluctuating environmental conditions. It maintains optimal function under humidity levels between 35% to 85%, making it versatile across various industrial settings.</p><p>The response time of less than 50 milliseconds ensures rapid detection capabilities crucial for safety applications. Additionally, its illuminance capacity reaches up to 1000 lux, allowing it to perform reliably under different lighting conditions. The emitting element utilizes an infrared LED which is non-modulated—ideal for straightforward detection tasks without interference complexities.</p><p>Adhering to international standards, this product carries CE marking alongside RoHS compliance and UL Recognition—assurances that underscore its quality and global applicability while meeting environmental directives on hazardous substances.</p><p>Weighing just 0.06 kg, it’s lightweight yet packed with features tailored for rigorous applications where every millisecond counts in safeguarding operations efficiently.</p>

Documents

  • IPD Product Catalogue

    IPD Product Catalogue V17
