<p>This industrial product is designed for those who value reliability and efficiency in their electrical systems. With a rated voltage of 690/220 VAC/VDC and 690/250 VAC/VDC, this device is built to handle demanding applications, making it suitable for both commercial and industrial settings. The rated frequency of 50/60 Hz ensures compatibility with standard power systems.</p><p>The product features a power loss of only 1.4 W, highlighting its energy-efficient design. It can withstand impulse voltages up to 6 kV and has a rated insulation voltage of 690 V, ensuring robust performance even in challenging environments. The contact configuration includes 0 normally closed (NC) and 3 normally open (NO) contacts, providing flexibility in application.</p><p>Equipped with screw-type terminals, the device allows for secure connections with a tightening torque range between 0.8-1.1 N-m. Its IP20 degree of protection indicates that it is protected against solid foreign objects larger than 12 mm but should be installed indoors or within an enclosure to safeguard against moisture ingress.</p><p>The dimensions are compact, measuring at a width of 52.5 mm, height of 57.5 mm, and depth of 46.7 mm—ideal for space-constrained installations without compromising on functionality.</p><p>Designed to operate efficiently across temperatures ranging from -25&#176;C to +55&#176;C, this unit remains reliable under various environmental conditions while offering storage capabilities from -40&#176;C to +80&#176;C.</p><p>Standards compliance is assured with approvals from IEC/EN standards including IEC/EN 60947-1, IEC/EN 60947-4-1, IEC/EN 60947-5-1 as well as UL standards UL60947-1 and UL60947-4-1 alongside the specific appliance safety standard IEC60335-2-40 A2L.</p><p>Connection versatility is another strong point; auxiliary circuit connecting capacity supports flexible wires with ferrules ranging from single or double wires at sizes between 1 sq-mm up to rigid configurations at sizes up to four sq-mm per wire type—ensuring ease during installation across different wiring setups.</p><p>Overall this product offers dependable performance backed by rigorous safety approvals making it an ideal choice when considering durable solutions tailored towards sophisticated electrical engineering demands within Australia’s technical landscape.</p>
