<p>When selecting an RCBO for your industrial or commercial applications, precision and reliability are key. This robust device is designed to provide overcurrent protection while ensuring residual current protection, making it a vital component in safeguarding electrical circuits.</p><p>With a rated current of 10 A and supporting voltages of 400/415 VAC, this RCBO is versatile enough to handle various demanding environments. Its rated impulse withstand voltage of 4 kV and insulation voltage of 500 V ensure that it can endure high-voltage surges without compromising performance.</p><p>This device features a short circuit capacity of 10 kA, which means it can effectively manage significant fault currents. The RCBO&#39;s electrical durability reaches up to 10,000 cycles, providing long-term reliability for continuous operation.</p><p>The construction includes three poles plus neutral (3P+N) with a curve type C characteristic, ideal for general-purpose applications where moderate inrush currents are expected. It also adheres to multiple standards such as IEC 61009-1, IEC 61009-2-2, and AS/NZS 61009-1, ensuring compliance with international safety requirements.</p><p>From an installation standpoint, the device measures at a width of 53.4 mm, height of 117.5 mm, and depth of 71.6 mm; these dimensions make it compact enough for space-constrained panels without sacrificing functionality. Weighing only 0.549 kg adds to its ease of handling during installation.</p><p>The power loss stands at a minimal 5.74 W—an efficient feature that helps reduce energy consumption over time. Rated frequency ranges between the common values of 50/60 Hz allowing compatibility across different regions or systems.</p><p>In terms of environmental resilience, this RCBO operates smoothly within ambient temperatures ranging from -5&#176;C to +55&#176;C and holds an IP20 degree of protection against solid objects larger than 12mm like fingers or tools—a crucial factor when considering safety in varying conditions.</p><p>For connectivity options: busbar connection capacity is set at up to ten sq-mm while rigid cables can go from one up to twenty-five sq-mm; flexible cables support one through sixteen sq-mm configurations offering flexibility according your setup needs whether using single-core solid wires or multi-wired arrangements.</p><p>The earthing switch type being undelayed ensures quick response times during faults enhancing overall system security alongside instantaneous operating characteristics making sure disruptions remain minimalized should issues arise unexpectedly</p><p>Designed under Overvoltage Category III classification signifies suitability even amidst environments prone towards transient voltages typically found throughout industrial settings</p><p>Overall if you require reliable comprehensive circuit protection solution capable meeting stringent industry standards look no further than this dependable RCBO choice tailored specifically meet diverse technical demands efficiently</p>
