<p>This robust RCBO is designed to meet the demanding needs of industrial and commercial applications, offering a blend of safety and efficiency. With a rated current of 50 A, it provides reliable protection against overloads and short circuits. The device operates at a rated voltage of 400/415 VAC, making it suitable for various electrical systems.</p><p>The RCBO features an impressive rated impulse withstand voltage of 4 kV and an insulation voltage of 500 V, ensuring resilience in challenging environments. It boasts a power loss value of just 20.41 W, which speaks to its energy-efficient design.</p><p>Constructed with a sturdy 3P+N configuration, this unit offers comprehensive protection across three phases plus neutral. Its compact dimensions—53.4 mm in width, 117.5 mm in height, and 71.6 mm in depth—allow for easy integration into existing panels without occupying excessive space.</p><p>Compliant with IEC standards (61009-1 and 61009-2-2) as well as AS/NZS standards (61009-1), this product guarantees adherence to international safety norms. With an IP20 degree of protection, it&#39;s safeguarded against solid objects greater than 12 mm but requires installation within enclosures for full environmental protection.</p><p>Weighing only 0.549 kg, the RCBO is lightweight yet durable enough to endure up to 10,000 electrical cycles—a testament to its long-lasting performance capability under continuous operation at frequencies between 50/60 Hz.</p><p>Its short circuit capacity stands at an impressive 10 kA while the cable cross-section accommodates both solid-core (1-25 sq-mm) and multi-wired connections (1-16 sq-mm). This flexibility ensures compatibility with various wiring setups found across different installations.</p><p>Designed with user-friendly connection options like busbar (10 sq-mm), rigid (1-25 sq-mm), and flexible cables (1-16 sq-mm), it simplifies installation processes significantly.</p><p>Operating efficiently within ambient temperatures ranging from -5&#176;C to +55&#176;C makes this RCBO adaptable for diverse climates found throughout Australia or similar regions worldwide; meanwhile maintaining overvoltage category III classification further enhances its protective capabilities against transient voltages typically encountered during lightning strikes or other disturbances on distribution networks.</p><p>With instantaneous operating characteristics enabled by C curve type response times combined alongside undelayed earthing switch functionality—this versatile device delivers unparalleled reliability when safeguarding sensitive equipment from potential harm caused by earth leakage currents detected via Type A residual current technology mechanisms embedded internally therein too!</p>
