ABB LS30P13B02 Limit Switch Plastic Roller Plunger 30mm W

Product Code: LS30P13B02

  • IP65 protection for harsh environments
  • Operates in -25 to 70°C range
  • CE and UL certified for quality assurance
  • Compact size: 30x30x84 mm
  • Durable with 10 million operations
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Product Type Limit Switch
Brand ABB
Actuating Speed 0.3 m/s
Actuator Material Plastic
Actuator Type Roller Plunger
Degree of Protection IP65
Height 84 mm
Length 30 mm
Mechanical Durability 10000000 Operations
Number of Auxiliary Contacts 2
Operational Temperature -25 to 70 deg C
Rated Current 3.1 A, 10 A, 5.5 A, 3 A
Rated Frequency 50/60 Hz
Standards and Approvals CE,UL
Switching Type Snap Action
Terminal Type Screw
Weight 0.064 kg
Width 30 mm

Description

<p>When considering the needs of industrial and commercial environments, selecting a reliable and robust switch is crucial. This particular product offers an impressive set of specifications that cater to various technical requirements.</p><p>The switch operates with a rated current range from 3.1 A to 10 A, accommodating diverse electrical demands. It supports a frequency of 50/60 Hz, making it versatile for different power systems. With an IP65 degree of protection, this switch is well-suited for harsh environments as it effectively resists dust ingress and water jets from any direction.</p><p>Designed to withstand operational temperatures between -25 to 70&amp;#176;C, this product can function efficiently across a wide temperature spectrum, ensuring reliability in both cold storage facilities and hot industrial settings.</p><p>Safety standards are paramount in any technical application. This device meets CE and UL standards and approvals, providing assurance of compliance with international safety regulations.</p><p>Compact yet efficient in design, the switch measures 30 mm by 30 mm by 84 mm (L x W x H), allowing for easy integration into existing systems without occupying excessive space. Weighing just 0.064 kg, it adds minimal weight while delivering maximum performance.</p><p>Equipped with two auxiliary contacts and employing a snap-action switching type, the device ensures quick response times critical in automated processes. The roller plunger actuator made from durable plastic provides consistent operation at an actuating speed of up to 0.3 m/s.</p><p>Installation is straightforward thanks to its screw terminal type which facilitates secure connections during setup or maintenance procedures. Additionally, boasting mechanical durability rated at ten million operations highlights its longevity even under frequent use scenarios.</p><p>This combination of features makes the product a dependable choice for professionals seeking efficiency coupled with resilience in their electrical components—an essential factor when evaluating potential additions or replacements within your system architecture.</p>
