For professionals seeking a robust solution for industrial and commercial electrical systems, this Automatic Air Circuit Breaker (ACB) offers a combination of reliability and efficiency. Designed to handle demanding environments, it is engineered to meet the specific needs of your power distribution network.
The ACB features a rated current range from 400 to 1000 amperes, making it versatile for various applications. With its rated voltage at 690 VAC, it ensures compatibility with high-voltage systems common in industrial settings. The breaker is capable of handling a breaking capacity of up to 66 kA, providing ample protection against overcurrents and short circuits.
Safety is paramount in any electrical system. This ACB meets IEC 309 standards, ensuring that it adheres to rigorous international safety and performance criteria. Its rated impulse withstand voltage stands at an impressive 12 kV, offering strong resistance against transient overvoltages typically caused by lightning strikes or switching surges.
The device boasts a rated short-time withstand current of 50 kA, which means it can endure significant fault currents without damage for a specified duration. This feature enhances the durability and reliability of your electrical installations.
Equipped with an Ekip Touch LSIG trip unit, this ACB provides advanced protection functions including long time (L), short time (S), instantaneous (I), and ground fault (G) protections. The intuitive touch interface allows for easy configuration and monitoring, ensuring that users can quickly adapt settings according to their specific requirements.
With four poles available, the breaker is suitable for three-phase systems with neutral connections. Its frame size E1.2 indicates compact dimensions without compromising on performance capabilities—ideal for installations where space may be limited but power demands are high.
The terminal type is designed as horizontal rear spread terminals which facilitate straightforward integration into existing panels or new setups alike—streamlining installation processes significantly while maintaining secure connections throughout operation cycles.
Power loss stands at just 156 watts under full load conditions—an efficient figure that contributes positively towards reducing overall energy consumption within your facility's infrastructure setup—a key consideration when assessing operational costs over time periods involved here too!
In summary: whether upgrading existing equipment or planning fresh implementations entirely anew; this Automatic Air Circuit Breaker offers dependable service backed by compliance across relevant industry-standard benchmarks today—and tomorrow!
