When considering a robust and reliable solution for your electrical distribution needs, the Motor Operated Air Circuit Breaker (ACB) stands out with its impressive technical specifications. Designed to meet the rigorous demands of industrial and commercial environments, this ACB ensures both safety and efficiency.
Starting with its rated current, which ranges from 640 to 1600 A, this product is versatile enough to accommodate various load requirements. Whether you're managing moderate or high-demand circuits, it provides consistent performance. The rated voltage of 690 VAC further supports its application in diverse settings, ensuring compatibility with standard industrial power systems.
Safety is paramount in electrical systems, and this ACB does not disappoint. With a rated impulse withstand voltage of 12 kV and a rated insulation voltage of 1000 VAC, it offers robust protection against transient overvoltages and ensures safe operation under normal conditions. Additionally, the breaking capacity of 66 kA guarantees that it can handle significant fault currents without compromising system integrity.
The trip unit featured in this model is the Ekip Touch LSIG. Known for its precision and reliability, the Ekip Touch LSIG provides advanced protection features including long-time (L), short-time (S), instantaneous (I), and ground fault (G) protections. This comprehensive suite safeguards your equipment from various electrical faults while minimizing downtime.
In terms of construction, the frame size E1.2 denotes a compact yet sturdy design that facilitates easy integration into existing panels or new installations. The horizontal rear spread terminal type enhances connectivity options while maintaining an organized layout within switchgear assemblies.
This ACB's rated short time withstand current is an impressive 50 kA—indicative of its ability to endure high fault levels momentarily without sustaining damage or causing interruptions in service continuity.
Energy efficiency remains crucial even in heavy-duty applications; hence, it's noteworthy that this circuit breaker maintains power loss at just 400 W during operation—balancing performance with energy conservation effectively.
Compliance with IEC 309 standards underscores its adherence to international safety regulations—a testament to quality assurance for users seeking dependable solutions aligned with global benchmarks.
In summary: if you're looking for an air circuit breaker capable of delivering reliable protection across varied operational scenarios while adhering strictly to established standards—the Motor Operated ACB fits seamlessly into any sophisticated electrical infrastructure demanding top-tier performance alongside stringent safety measures—all wrapped up under one comprehensive package tailored specifically towards meeting professional expectations head-on!
