The Automatic Air Circuit Breaker (ACB) you're considering offers a robust solution for managing high-power electrical systems. With its adaptable rated current range of 1000 to 2500 A, this ACB is well-suited for various industrial and commercial applications where reliable power distribution is crucial.
Designed to handle significant electrical demands, the breaker boasts a rated impulse withstand voltage of 12 kV and an insulation voltage of 1000 VAC. These specifications ensure that the device can manage sudden surges effectively while maintaining safety and operational integrity.
One of the standout features is its impressive breaking capacity of 66 kA, which matches its rated short-time withstand current. This capability ensures that the circuit breaker can interrupt fault currents efficiently, providing essential protection against overloads and short circuits in demanding environments.
The Ekip Touch LSIG trip unit integrated into this model enhances operational control by offering comprehensive protection settings such as long-time, short-time, instantaneous, and ground fault protection. Such versatility allows precise adjustments tailored to specific system requirements, enhancing both safety and efficiency.
This ACB's frame size is classified as E2.2 with a four-pole configuration, making it versatile enough to accommodate complex electrical networks. Additionally, the horizontal rear spread terminal type facilitates straightforward installation in existing setups without significant modifications.
Power loss stands at 550 W under full load conditions — a factor worth considering when assessing overall system efficiency and heat management within your setup.
Complying with IEC 309 standards and approvals underscores its commitment to international safety protocols while ensuring compatibility across global installations. This adherence guarantees dependable performance aligned with industry benchmarks for quality assurance.
In summary, this Automatic ACB is engineered for durability and adaptability in rigorous environments where performance cannot be compromised. Its comprehensive feature set provides substantial flexibility for integration into diverse projects requiring meticulous energy management solutions without sacrificing reliability or safety standards typically expected from top-tier equipment in today's market landscape.
