When it comes to ensuring reliable protection and control in industrial and commercial electrical systems, the Motor Operated Air Circuit Breaker (ACB) is a key component. This specific model offers a robust solution with its impressive specifications, making it suitable for various demanding applications.
The ACB is designed to handle a rated current range of 1280-3200 A, providing flexibility for different operational needs. With a rated voltage of 690 VAC and an insulation voltage of 1000 VAC, this breaker ensures safe operation in high-voltage environments. It also boasts a significant breaking capacity of 100 kA, which allows it to efficiently interrupt fault currents without compromising system integrity.
One standout feature is its rated short time withstand current of 85 kA. This characteristic enables the breaker to manage transient conditions effectively, offering an added layer of security during unexpected electrical surges or faults. The device's frame size is E4.2, tailored for installations where space efficiency is crucial without sacrificing performance.
The trip unit integrated into this ACB is the Ekip Touch LSIG type. This advanced unit provides precise protection settings and real-time monitoring capabilities that enhance operational reliability and safety. Users can easily interact with the touch interface for configuring parameters or accessing data logs.
For those concerned about energy efficiency, it's noteworthy that this breaker has a power loss rating of 743 W—an important consideration when evaluating overall system efficiency and cost-effectiveness over time.
With three poles included in its design, this ACB supports balanced load distribution across phases while maintaining stability within multi-phase systems. The terminal type features horizontal rear spread terminals which facilitate straightforward installation processes and ensure secure connections in complex setups.
Compliance with IEC 309 standards underscores the quality assurance embedded within this product's design and manufacturing process—a critical factor for professionals seeking devices that meet stringent international safety regulations.
In summary, whether you're upgrading existing infrastructure or implementing new projects requiring dependable circuit protection solutions, this motor operated ACB delivers on all fronts: performance versatility compliance with global standards ease-of-use through modern interfaces efficient energy management—all wrapped up in one reliable package.
