ABB ATB953E Earth Terminal Block 6 -Connection Aluminium 95sq-mm 230A Cu 180A AL Yellowith Green

Product Code: ATB953E

  • Supports 180 A, 230 A current ratings
  • Dual colour options: Yellow, Green
  • Accommodates up to 6 connections
  • Rated insulation voltage of 800 V
  • Handles cable cross-section of 95 sq-mm
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Maximum Cable Cross Section (mm²) 95
No. of Connections 6
Nominal Insulation Voltage (V) 800
Nominal Current (A) 230 (Cu)/180 (AL)
Screw Head Size (mm) 5
Tightening Torque (Nm) 20
Product Type Earth Terminal Block
Brand ABB
Cable Cross Section 95 sq-mm
Colour Yellow, Green
Housing Material Aluminium
Number of Connections 6
Operational Temperature 80 deg C
Rated Current 180 A, 230 A
Rated Insulation Voltage 800 V
Screw Size 5 mm
Tightening Torque 20 N-m

Description

Aluminium terminal block with 6 connections for cable size 95mm². It is yellow/green in colour and has a nominal current of Cu 230A & Al 180A, as well as a nominal insulation voltage of 800V. This terminal block is suitable for both copper and aluminium cables. The tin plating prevents galvanic reactions. It also features an internal barrier that allows the connection of aluminium and copper cables to a single block. The screw head size is 5mm, and it can be mounted on a din rail or panel.
